Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid / Air
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.54
  • Stroke (in):
    2.44
  • Displacement (cc):
    398
  • Carburetion Brand:
    Mikuni
  • Fuel Injector:
    No
  • Carburetor:
    Yes
  • Number Of Carburetors:
    1
  • Carburetion Type:
    Carburetor
  • Bore x Stroke:
    90.0 x 62.6 mm (3.54 x 2.44 in.)
  • Compression Ratio:
    11.3:1
  • Fuel System:
    Mikuni BSR36, single carburetor
  • Lubrication:
    Semi-dry sump
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
  • Overdrive:
    Yes
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    87.6
  • Width (in):
    33.7
  • Height (in):
    47.2
  • Wheelbase (in):
    57.5
  • Ground Clearance (in):
    10.2
  • Fuel Capacity (gal):
    2.6
  • Wet Weight (lbs):
    321
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Front Suspension Brand Name:
    Showa®
  • Steering Damper:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Tube / Tubeless:
    Tubed
  • Front Tire (Full Spec):
    120/70 R17 M/C 58H
  • Rear Tire (Full Spec):
    140/70 R17 M/C 66H
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
  • Anti-Lock Brakes:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
  • Front Brake Diameter (in):
    11.8
  • Rear Brake Diameter (in):
    9.5
