Specifications

• ENGINE

  add remove
  • Engine Type:
    Horizontal In-line
  • Cylinders:
    4
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    16
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    2.64
  • Stroke (in):
    1.78
  • Displacement (cc):
    636
  • Compression Ratio:
    12.9:1
  • Carburetion Brand:
    Keihin
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Torque (Ft Lbs):
    52.1
  • Horsepower (bhp):
    136
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
  • Final Drive Ratio:
    2.86
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    79.7
  • Width (in):
    28
  • Height (in):
    43.3
  • Wheelbase (in):
    55.1
  • Ground Clearance (in):
    5.1
  • Wet Weight (lbs):
    430
  • Fuel Capacity (gal):
    4.5
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    4.7
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Rear Suspension Brand Name:
    UNI-TRAK®
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    5.9
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    Showa®
• WHEELS & TIRES

  add remove
  • Tube / Tubeless:
    Tubeless
  • Front Tire (Full Spec):
    Bridgestone® Battlax Hypersport S22: 120/70ZR17M/C (58W)
  • Rear Tire (Full Spec):
    Bridgestone® Battlax Hypersport S22: 180/55ZR17M/C (73W)
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.2
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    8.7
  • Brake Brand Name:
    Nissin
• SEATS

  add remove
  • Seat Type:
    Two-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Height (in):
    32.7
  • Number Of Seats:
    2
